is an integral part of overall building design, as it can contribute to the aesthetics, comfort and performance of any facade. Obtaining the best performance in these aspects depend on good design, proper construction practices and correct installation. ALUMATE SCREENING

Design requirements for screening in buildings are generally the same regardless of the screening material used, ongoing maintenance and fire performance are currently and will continue to prove as important considerations.

ALUMATE - ALUMINIUM SCREENING

ALUMATE architectural screening system, enhances the look and feel of outdoor façade, soffit and internal wall & ceiling linings. ALUMATE is Ideal for new buildings or renovations and is suitable for both residential and commercial applications where a low maintenance, highly durable, non- combustible realistic wood grain finish is required.

ALUMATE screening comes in a varying batten widths and offers concealed straight forward fixing methods making it a highly flexible for any design specification and application. ALUMATE screening can be orientated either vertically or horizontally with either a single or mixture of profile sizes in order to deliver a unique clean finish with any desired arrangement.

Advantages

  • Non-Combustible
  • Low maintenance
  • Durable
  • Easy installation with Concealed Lock In fixing method
  • Come with the rear clip to lock the batten on to
  • Profile Coverage: 50mm
  • Profile Depths: 50mm, 100mm and 150mm
  • Wide range of realistic wood grain finishes, coated on all faces
  • Vertical or horizontal installation options
  • Mix and match the profiles to create a unique installation

NON-COMBUSTIBLE

Alumate Aluminium Cladding has been tested and certified to AS1530.1 as a Non-Combustible material.

Specifications

  • Grade 6063-T5 Aluminium extrusion profiles and accessories
  • Decoral Aluminium heat transfer surface finishing
  • Certified AS 1530.1-1994 Compliant – Non-Combustible
  • Density 2712 kg/m³
  • Ultimate Tensile Strength 140 MPa
  • Yield Strength 97 MPa
  • Young’s Modulus 69 GPa
  • Melting Temperature 615°C
  • Thermal Conductivity 201-218 W/m°K

Decoral - Italian Timber Finishes

Alumate cladding combines aluminium extrusions with the latest Italian decorative heat transfer surface finishing process technology. The result is in a low maintenance cladding that exhibits excellent strength and durability whilst maintaining the most realistic aesthetically pleasing alternative to natural timber

The patented Decoral system transfers the colour and appearance of wood grain onto the surface of the aluminium profiles. This system is compliant to worldwide finishing quality labels making it the superior choice for architectural cladding.

* PLEASE BEAR IN MIND THAT COLOURS MAY APPEAR SLIGHTLY DIFFERENT ON DELIVERY DUE TO DIFFERENT PRINTER AND MONITOR SETTING.
